規格

Size

額定動力矩
Rated Dynamic
Torque
N.m

額定靜力矩
Rated Static
Torque
N.m

空效力矩
Drag Torque
( ≤ )N.m

接通時間
Engagement
Time
( ≤ )S

斷開時間
Disengagement Time
( ≤ )S

額定電壓
Rated
Voltage
DCV

線圈消耗功率 ( 20 ℃ )
Coil Consumption
power( 20 ℃ )
W

允許最高轉速
Allowed Max
Revolution
r/min

重量
Weight
kg

供油流量
Oil Flow
Rates
L/min

1.2/1.2C

12

20

0.39

0.28

0.09

24

10

3500

1.3

2.5

25

40

0.40

0.30

0.09

24

17

3500

1.73

5/5C

50

80

0.90

0.32

0.10

24

17

3000

2.9

10/10C

100

160

1.80

0.35

0.l4

24

29

3000

4.3

16

160

250

2.40

0.37

0.14

24

26

2500

5.8

25/25C

250

400

3.50

0.40

0.18

24

39

2200

7.7

40

400

630

5.60

O.42

0.20

24

45

2000

12.2

63

630

1000

9.00

0.45

0.25

24

66

1800

16.2

100

1000

1600

15.0

0.65

0.35

24

81

1600

23.2

1.2

160

1600

2500

24.0

0.90

0.45

24

87

1600

31.7

1.5

250

2500

4000

37.50

1.20

0.60

24

100

1200

47

2.0

400

4000

6300

60.00

1.50

0.80

24

134

1000

100.9

3.0
